The omega link is a connecting link, but without hinge function. The link can also be used as end fitting on a chain. For example at chain slings. G80 Omega Links are commonly used in conjunction with recessed Head Rings and Chain for Chain Slings. They are also a popular fitting for variable type slings.
Product Features:
• Grade 80 component.
• Made from super alloy steel.
• Conforms to AS3776.
• Yellow painted, other color is available as per request.
• Working load limit permanently shown on the body.
Specifications
| G80 OMEGA LINK | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| ITEM NO | SIZE | WEIGHT | WLL | B.L | A | B | D | H | L |
| MM | KG/PC | TON | TON | MM | MM | MM | MM | MM | |
| RL-OL5-205 | 6 | 0.12 | 1.12 | 4.48 | 8 | 41 | 20.5 | 25 | 52 |
| RL-OL5-206 | 7/8 | 0.22 | 2 | 8 | 10 | 52 | 23.5 | 35 | 68.5 |
| RL-OL5-207 | 10 | 0.36 | 3.15 | 12.6 | 12 | 62 | 31.5 | 40.5 | 81 |
| RL-OL5-208 | 13 | 0.71 | 5.3 | 21.2 | 15 | 81 | 41 | 54 | 108 |
| RL-OL5-209 | 16 | 1.3 | 8 | 32 | 19 | 99 | 49.5 | 64 | 126 |
| RL-OL5-210 | 20 | 2.2 | 12.5 | 50 | 23 | 118 | 58 | 75.6 | 152 |
