Specifications
| FERRULE CODE. | A(mm) | B(mm) | S(mm) | L(mm) | WEIGHT Kgs/1000Pcs |
|---|---|---|---|---|---|
| 1 | 1.3 | 2.6 | 0.85 | 5 | 0.32 |
| 1.5 | 1.8 | 3.6 | 1.05 | 6 | 0.72 |
| 2 | 2.4 | 4.8 | 0.85 | 7 | 0.82 |
| 2.5 | 2.7 | 5.4 | 1.10 | 9 | 1.70 |
| 3 | 3.3 | 6.6 | 1.35 | 11 | 2.90 |
| 3.5 | 3.9 | 7.8 | 1.60 | 13 | 4.50 |
| 4 | 4.3 | 8.8 | 1.70 | 14 | 6.20 |
| 4.5 | 5.1 | 10.2 | 1.90 | 16 | 8.90 |
| 5 | 5.6 | 11.2 | 2.10 | 18 | 12.20 |
| 6 | 6.7 | 13.4 | 2.50 | 21 | 20.00 |
| 6.5 | 6.9 | 14.0 | 2.70 | 23 | 27.00 |
| 7 | 7.5 | 15.0 | 3.00 | 25 | 32.00 |
| 8 | 8.5 | 17.0 | 3.50 | 28 | 47.00 |
| 9 | 9.9 | 19.8 | 3.70 | 32 | 68.00 |
| 10 | 10.9 | 21.8 | 4.10 | 35 | 90.00 |
| 11 | 11.6 | 23.2 | 1.20 | 39 | 122.00 |
| 12 | 13.2 | 26.4 | 4.90 | 42 | 158.00 |
| 13 | 14.2 | 28.4 | 5.40 | 46 | 198.00 |
| 14 | 15.3 | 30.6 | 5.80 | 49 | 243.00 |
| 16 | 17.5 | 35.0 | 6.70 | 56 | 366.00 |
| 18 | 19.0 | 38.0 | 7.80 | 63 | 529.00 |
